Model KM 6213BIN Digital High Voltage Insulation Tester

Send Inquiry

Request To Call Back

Model KM 6213BIN Digital High Voltage Insulation Tester

Name: Model KM 6213BIN Digital High Voltage Insulation Tester
Brand: INDUSTRIAL SUPPLY SYNDICATE

Get a Price/Quote

MOQ : 10 Pieces

Model KM 6213BIN Digital High Voltage Insulation Tester Specification

Accuracy
(5% of reading + 5 digits)

Measuring Range
0.0 M - 200G

Features
High voltage output, data hold, backlight, safety interlock, portable hard case

Response Time
Instantaneous on Measurement

Frequency
DC measurement, Power: 50/60Hz

Specimen Size
Varies by Probe Attachment

Display Type
Large Digital LCD Display

Humidity
85% RH (no condensation)

Test Range
0.0 M to 200G

Mounting Type
Portable

Interface Type
Standard Test Leads (banana jack type)

Port Size
Standard Test Lead Connections

Resolution
0.01 M

Automation Grade
Automatic measurement with manual range setting

Operating Voltage
Selectable - 500V, 1000V, 2500V, 5000V, 10000V

Temperature
0C to 40C (Operating)

Number of Specimens
Single Specimen Testing

Power Supply
AC 220V 10%, 50/60Hz

Equipment Type
Digital High Voltage Insulation Tester

Application
Insulation resistance measurement of high-voltage electrical equipment

Usage
Electrical insulation resistance testing

Machine Weight
Approx. 2.6 kg

Control Mode
Manual/Automatic

Test Modes
Insulation resistance, Voltage measurement, PI and DAR testing

Alarm Function
Over-range, Live circuit warning, Low battery

Memory Function
Stores up to 99 sets of data

Output Current
Max 1.2 mA (at test voltage)

Carrying Case Material
Durable plastic, yellow with instructions inside lid

Voltage Withstand
5000V AC (1 min)

Accessories Included
Test leads, Power cord, User manual, Carry case

Battery Backup
Enabled

Safety Rating
Meets CAT IV 600V / CAT III 1000V standards

Dimensions
Approx. 315mm 250mm 125mm

Model KM 6213BIN Digital High Voltage Insulation Tester Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
7 Days

About Model KM 6213BIN Digital High Voltage Insulation Tester

Shop Now for the KM 6213BIN Digital High Voltage Insulation Tester-a praiseworthy and hot-selling instrument designed for accuracy and reliability. This crowning tool offers cost-effective insulation resistance testing up to 200G with selectable test voltages up to 10,000V. Towering above competitors, it features CAT IV 600V/CAT III 1000V safety, a large LCD display, data memory for 99 readings, and instant alarms. Its durable yellow carrying case makes transportation effortless, while superior automation and remarkable accuracy position it as the smart choice for professionals.

Versatile Applications and Uses

The Model KM 6213BIN Digital High Voltage Insulation Tester excels in a wide variety of electrical insulation resistance measurements, making it essential for testing high-voltage cables, transformers, switchgear, and rotating machinery. Its flexibility covers both specific industrial needs and general electrical maintenance. Additionally, this device supports other applications such as periodic safety checks, troubleshooting insulation faults, and commissioning new installations-making it a valuable asset in manufacturing, utilities, and testing laboratories.

Certifications, Logistics, and Export Market Reach

With rigorous adherence to international CAT IV 600V and CAT III 1000V safety standards, the KM 6213BIN is engineered for global acceptance. FOB delivery from India streamlines export logistics, ensuring competitive outlay and reliable transit. Typical delivery times are optimized for quick turnaround, facilitating seamless operations in the export market. Backed by its certifications and logistical prowess, this insulation tester serves dealers, exporters, and industrial users worldwide with dedication and efficiency.

FAQ's of Model KM 6213BIN Digital High Voltage Insulation Tester:

Q: How does the KM 6213BIN ensure safe insulation testing?

A: The tester meets CAT IV 600V and CAT III 1000V safety ratings, features a safety interlock, live circuit warning, over-range alarm, and offers a durable case to protect users and equipment during high-voltage tests.

Q: What is the process for storing and recalling measurement data?

A: The KM 6213BIN supports memory functionality, allowing users to store up to 99 test results, which can be easily recalled for further analysis or record-keeping, enhancing efficiency and traceability on the job.

Q: Where can the KM 6213BIN tester be applied?

A: This insulation tester is ideal for industrial sites, power plants, laboratories, electrical maintenance workshops, and for field testing on high-voltage electrical equipment such as transformers, cables, and motors.

Q: What are the main benefits of using the KM 6213BIN Digital Insulation Tester?

A: Users benefit from its high measurement range, quick response time, accuracy, memory retention, safety features, portability, and multiple test modes, making insulation evaluation both cost-effective and reliable.

Q: When should the insulation resistance of equipment be checked with this tester?

A: Insulation resistance should be tested during periodic maintenance, after installation, before commissioning, and whenever insulation breakdown is suspected to ensure continued safety and performance.
