Flue Gas Analyser

• Equipment Type
• Combustion Check Gas Analyser

• Accuracy
• O2: 0.2% / CO: 10 ppm or 5% of reading (whichever is greater)

• Application
• Industrial Boilers, Burners, Combustion Engines, Furnaces

• Automation Grade
• Semi-automatic

• Control Mode
• Manual and Automatic options

• Display Type
• Digital LCD Display

• Features
• Lightweight, portable, auto data logging, memory storage, easy calibration

• Gas Pressure
• Atmospheric pressure

• Humidity
• 0-99% RH

• Interface Type
• Mini-USB, RS232

• Machine Weight
• Approx. 700 g

• Measuring Range
• O2: 0-21% / CO: 0-2000 ppm / CO2 (calculated): 0-25%

• Mounting Type
• Handheld

• Number of Specimens
• Single-point measurement

• Operating Voltage
• 9 V rechargeable battery / Power adapter

• Port Size
• Compatible with standard probe connectors

• Power Supply
• Via rechargeable battery

• Resolution
• O2: 0.1% / CO: 1 ppm

• Response Time
• Typically <30 seconds

• Temperature
• 0C to 40C

• Test Range
• Varies per gas (see measuring range)

• Usage
• Combustion efficiency testing, flue gas analysis

• Equipment Type
• Portable Flue Gas Analyzer

• Accuracy
• CO: 5% of reading or 10 ppm; O2: 0.2%

• Application
• Measurement of flue gases in boilers, burners, and heating systems

• Automation Grade
• Automatic

• Control Mode
• Microprocessor-based

• Display Type
• Large Backlit LCD Digital Display

• Features
• Data Logging, Auto Calibration, Date/Time Display

• Gas Pressure
• 0-2 bar

• Humidity
• 15% - 90% RH (Non-condensing)

• Interface Type
• RS232/USB (varies by model)

• Machine Weight
• Approx. 500 g

• Measuring Range
• O2: 0-21%, CO: 0-2000 ppm

• Mounting Type
• Handheld/Portable

• Operating Voltage
• 6V (Battery) / 12V (Adapter)

• Port Size
• Standard Flue Probe Port

• Power Supply
• Rechargeable Battery 4xAA or External 12V Adapter

• Resolution
• O2: 0.1%; CO: 1 ppm

• Response Time
• <60 seconds

• Temperature
• Operating: 0C to +50C

• Test Range
• CO: 0-2000 ppm, O2: 0-21%

• Usage
• Analysis of Exhaust/Flue Gases
